TVLogic LUM-550M3 55" True UHD 4K LCD Monitor

TVLogic LUM-550M3 55" True UHD 4K LCD Monitor

£5,212.53 (ex VAT)
£6,255.04 (inc VAT)
SKU: TVL-LUM-550M3

Current Stock:

Adding to cart… The item has been added

TVLogic LUM-550M3 55" True UHD 4K LCD Monitor



The TVLogic LUM-550M3 UHD LCD Monitor with 3840 x 2160p resolution and 1100:1 contrast ratio provides crisp and sharp content quality. It has a 178° wide viewing angle for consistency from every direction and button controls to adjust the monitoring functions. This monitor has eight input and output SDI ports to support 3G-SDI and 12G-SDI videos with 12G-SDI ports for single-link connectivity.



Key Features:

  • 54.6” True UHD Resolution (3840×2160)
  • Max Luminance 700nits
  • Waveform / Vectorscope
  • Audio Level Meter
  • Marker
  • Timecode Display
  • Closed Caption (CC-608, CC-708)
  • HDR Emulation (PQ, HLG, S-Log3)
  • 12G-SDI Single Link 4K/UHD
  • 3G-SDI Quad-Link Square Division & 2-S.I. 4K/UHD
  • IR Remote Control
  • Ultra Slim Bezel



LCD Panel:

Size 54.6"
Resolution 3840 x 2160 (16:9)
Pixel Pitch 0.315(H) x 0.315(V) mm
Colour Depth 1.07B Colours
Viewing Angle 178(H)/ 178(V)
Luminance of white 700cd/m2
Contrast Ratio 1100:1
Display Area 1209.6(H) x 680.4 (V) mm

Input:

4 x BNC 12G/6G/3G/HD/SD-SDI Ch1/Ch2, 3g/HD/ SD-SDI Ch3/Ch4
1 x HDMI  HDMI (2.0) Input

Output:

4 x BNC

12G/6G/3G/HD/SD-SDI Output 1Ch

By Pass Mode: SDI A/B Channel (Active Through Out)

12G Mode: 3840 X 2160 60P/59.94/50P

Input Signal

12G-SDI 12Gb/s
6G-SDI 6Gb/s
3G-SDI 2.970Gb/s
HD-SDI  1.485Gb/s
HDMI  720p/1080p/2160p

SDI Input Signal Formats

SMPTE ST2048-1 4096 x 2160 (50~60p)
SMPTE ST 2082-10 Mode1 3840x2160 60p/59.94p/50p (12G-SDI x 1Ch)
SMPTE ST 2081-10 Mode1 3840x2160 30p/29.97p/25p/24p*/23.98p*
(6G-SDI x 1Ch)
SMPTE ST4025-5 3840x2160 60p/59.94p/50p (3G-SDI x 4Ch)
SMPTE ST274 3840x2160 30p/29.97p/25p/24p*/23.98p*
(HD-SDI x 4Ch)**
SMPTE-425M

1920x1080 60p/59.94p/50p (3G-SDI LEVEL A)

1920x1080 60i/59.94i/50i/30p/29.97p/25p
/24p*/23.98p* (3G-SDI LEVEL B)

1280x720 60p/59.94p/50p (3G-SDI LEVEL B)
SMPTE-274M 1920x1080 60i/59.94i/50i/30p/29.97p/25p
/24p*/23.98p*
SMPTE-296M 1280x720 60p/59.94p/50p
SMPTE-259M 720x487 59.94i, 720x576 50i

HDMI Input Signal Formats

V2.0 3840x2160 60p/59.94p/50p
(RGB/YCbCr 4:4:4 8bpp Mode)
V1.4  3840x2160 30p/29.97p/25p/24p*/23.98p*
(RGB/YCbCr 4:4:4 8bpp Mode)
V1.2

1920x1080 60i/59.94i/50i/30p/29.97p/25p
/24p*/23.98p* (RGB/YCbCr 4:4:4 8bpp Mode)
60p/59.94p/50p

1280x720 60p/59.94p/50p
(RGB/YCbCr 4:4:4 8bpp Mode)

General

Audio In SDI Embedded Audio (Group, Channel Selectable)
Audio Out Analog Stereo (3.5MM Phone Jack)
Power

AC100~240V (50~60Hz)
Power Consumption

150 Watts (Max.)
Operating Temperature 0C to 35C (32F to 95F)
Storage Temperature -20C to 60C(-4F to 140F)
Dimensions(Main Body)

1262 x 746 x 81.4 (mm)

49.68 x 31.72 x 9.64 (inch)
Dimensions (With Stand)

1262 x 794.5 x 245 (mm)

49.68 x 31.27 x 9.64(inch)
Weight 35.8kg/78.92lbs
Included Accessories AC Power Cable, IR Remote, Table Stand
