AJA I/O Express *Clearance (ex showroom)*

£700.00 (ex VAT)
£50.00 (ex VAT)
£60.00 (inc VAT)
SKU: AJA I/O Express *Clearance (ex showroom)*

Current Stock:1

Availability: Normally Available in 3-5 Days
Adding to cart… The item has been added

AJA I/O Express - Ex Showroom, no box *Clearance*

Io Express is the perfect Mac or PC interface for anyone who needs a quality portable monitoring and mastering solution when working with Apple ProRes 422 and Apple ProRes 422 (HQ), XDCAM HD, DVCPRO HD, and more. Built small and robust, Io Express is ideal for use with Ki Pro and a laptop for onset editing and playout.

Featuring full 10-bit, broadcast-quality HD to SD hardware down-conversion and automatic HD/SD 12-bit component analog output, Io Express offers conversion flexibility all the time - during ingest or playback.

If you work with a wide variety of formats, frame rates and audio/video sources, Io Express provides the connectivity you need. With its small footprint it offers big features, like 10 or 8-bit uncompressed video, HDMI I/O, HD/SD-SDI I/O with 8 channels of embedded audio, analog component video (SD/HD) or composite output, 2-channel unbalanced audio output, and broadcast quality hardware based down-conversion for flexible post production. The HDMI I/O is v1.3a at 30 bits per pixel, providing ideal support for the very latest 10-bit monitors.






  • HD/SD-SDI input/output
  • HDMI v1.3a input/output with Deep Color support at 30 bits per pixel
  • HD/SD Component Video output
  • 10-bit HD to SD Hardware Downconvert
  • 2-Channel RCA audio output
  • LTC input/ouput (selectable LTC Input/Reference Video Input)
  • RS422
  • Expresscard/PCIe interfaces, over 1-lane PCIe cable (two Io Express configurations can be ordered: with Expresscard for laptops, or with PCIe card for Mac Pro or Windows workstation)
  • For Mac OSX and Windows 7/XP/Vista/
  • Support for Final Cut Studio and Adobe Creative Suite
  • Small, portable case design
  • 1-meter PCIe tether cable
  • 12v DC power supply
  • Rackmount kit optional





Options Rackmount kit
PCIe card interface or ExpressCard/34
MacBook Pro or Windows Laptop Ingests DVCPRO HD
DV25/DV50
SD Uncompessed
Apple ProRes 422 (Mac Pro and MacBook Pro only)
SD and limited HD
MacBook Pro or Windows Laptop Plays Back DVCPRO HD
DV25/DV50
SD Uncompessed
Apple ProRes 422 HD/SD (Mac Pro and MacBook Pro only)
HDV
XDCAM
XDCAM EX, XDCAM HD
Note: Encoding of Apple ProRes 422 and Apple ProRes 422 (HQ) is available only on Apple computers. Apple ProRes 422 and Apple ProRes 422 (HQ) can be played back on a PC with the appropriate QuickTime Windows decoder.
