Manfrotto 504X Fluid Video Head
£299.00 (ex VAT)
£358.80 (inc VAT)
SKU: Manfrotto 504X Fluid Video Head MVH504XAH
Current Stock:
504X fluid video head is the evolution of the hugely successful 504HD. It's a more compact and lighter version that finally comes with flat base (base diameter 75 mm), developed to meet the needs of the most demanding videographers. New Easy Link Connectors New easy link connectors come with Manfrotto anti rotation technology and Arri pin. The pan bar attachments on both left and right sides of the head give maximum flexibility. On the left side a cap, that cover 3/8” easy link connector, to avoid cutting during the use. 4 Steps CBS The head offers unrivalled stability and allows smooth shooting thanks to 4-steps counterbalance System up to 6,5 kg/14,3 lbat 55 mm/2,2 in C.O.G. STEP 0: off STEP 1: 2,2 kg / 4,8 lb STEP 2: 4,4 kg / 9,7 lb STEP 3: 6,5 kg / 14,3 lb Flat Base More options for shooting Sliding Quick Release Plate Sliding plate attachment side-lock mechanism allows safe, quick and easy camera attachment, keeping video equipment stability and balance. New Fluid Technology The variable continuous fluid drag system Brakes Independent brakes on TILT and PAN axes. Bubble Level The back bubble level lets you level the heads even in low light conditions.
Availability: Available in 3-5 working days
The head is made from a brand-new catching aluminium design, and has a maximum payload of 12kg.
Utilising Manfrotto’s new fluid technology, the camera head allows you to capture judder-free smooth motion pans and tilts. It's never been easier for the operator to create premium-quality video capture, thanks to a 4-step counterbalance system which can carry payloads of up to 6.5 kg at 55mm C.0.G. That makes using a wide range of different cameras easier and more practical.
Two easy link 3/8'' thread connections allow an external monitor or other accessory equipment to be fitted on the head side. On the left side there is a cap cover on the 3/8” easy link connector to avoid cutting during usage.
The sliding-plate side-lock attachment enables quicker set up of the camera, keeping video equipment stable and balanced. Head levelling is simple thanks to the clever backlit levelling bubble.
on sliders, jibs or other accessories.
is powered by a new fluid technology, which
sets a new level of performance in the Manfrotto range, boosting the smoothest
and judder-free pan and tilt movements.
The 504X increases the capability of keeping
the heavy equipment safe, stable and in position.
Weight
2kg
Safety Payload UNI/PdR 105:2021
12kg
Counterbalance System
Variable Steps
Counterbalance Weight
2.2, 4.4, 6.5 kg
Base Diameter
75mm
Material
Aluminium
Bubble Spirit Level (no.)
1
Centre of Gravity
55mm
Powered by (batteries)
Lithium
Certifications
WEEE; RoHS
Top Attachment
1/4″ screw, 3/8″ screw
Colour
Black
Easy Link
yes
Front Tilt
-70° / +90°
Head Type
Fluid/ Video
Maximum Working Temperature
60 °C
Minimum Working Temperature
-30 °C
Pan Bar included
yes
Pan Drag
continuously adjustable from 0 to max level
Panoramic Rotation
360 °
Plate Type
504PLONGR-1
Quick Release
yes
Tilt Drag
continuously adjustable from 0 to max level
Working Height
14.9cm
Accessory Compatibility
MVAPANBARM; MVAPANBARL
