Miller ArrowFX 3 Fluid Head

Miller
SKU:
Miller Arrowx 7 Fluid Head 1076
Availability:
Available for Next Working Day Delivery
£6,010.80 (Inc. VAT)
£5,009.00 (Ex. VAT)
Current Stock:
Adding to cart… The item has been added

Miller Arrowx 7 Fluid Head (1076)

The Miller 1076  follows in the tradition and reputation of the world-renowned Arrow series. The all-new Arrowx 7 sets new dimensions in professional camera support, augmenting the power of expression of creative professionals.

Featuring a wide payload range and precision fluid drag. Incorporating the Miller innovative 16 position CB Plus counterbalance system; the Arrowx 7 delivers the flexibility, speed and accuracy, that professionals expect and demand.

The Miller 1076 Arrowx 7 Fluid Head, 6-25kg (13.2-55.1lbs) payload range and 7 0 selectable pan-tilt fluid drag positions make it ideal for EFP, Studio and Field OB . It can be used with a wide range of cameras, lenses and accessories.

CB Plus is an innovative sequential counterbalance design, taking traditional counterbalancing a step forward ahead of the rest. This resulting in repeatable, accurate and rapid setup. CB Plus features eight larger counterbalance steps, allowing the user to get to their required counterbalance position quickly and efficiently.

The CB Plus "one flick" switch conveniently located at the front of the head, adds a half step between each of the eight larger steps enabling counterbalance fine-tuning when required.

The new Arrowx 7 comes with the reliability and "THE RIGHT FEEL" that are the hallmarks of every Miller product.

  • Compact, lightweight and versatile.
  • 7 selectable positions of fluid pan and tilt drag +0.
  • 16 position CB Plus™ counterbalance system.
  • Wide payload range 6-25kg (13.2-55.1lbs).
  • Fluid drag system with smooth start and soft stop technology & balanced diagonal transitions.
  • Controls "all in one location" design for fast easy and practical use.
  • Illuminated bubble level and pan-tilt drag controls.
  • Precise floating pan-tilt calliper locks ensure bounce free on-off performance.
  • Quick release, 120mm sliding camera platform with camera plate (euro).
  • Removable ball level stud allows for flat base mounting with 3/8" screw thread.
  • Mitchell base adaptable.
  • Robust construction for rugged outdoor shooting conditions.
  • Optional second pan handle mount.
  • Side mounting point for viewfinders and accessories.
  • 3 year warranty.
Payload Range 6.0-25.0kg (13.2-55.1lbs)
Weight 3.4kg (7.4lbs)
Counterbalance Positions 16 selectable positions
Pan Tilt Drag 7 selectable fluid drag positions + 0
Pan Tilt Locks Positive lock calliper brake system
Tilt Range + 90°/ -75°
Pan Range 360°
Camera Platform Quick release camera plate (Euro)
Sliding Range 120mm (4.7)
Mounting Base Ø100mm (3.9") ball levelling with 3 x M5 holes for flat base mounting
Height Above Bowl 162mm (6.4")
Illuminated Controls Bubble level, pan-tilt drag controls
Pan Handle Telescopic 390-590mm (15.4-23.2")
Temperature Range -40° to +65°C (-40° to +149°F)
